| Flywheel Diameter | 12.992 |
| Flywheel Inner Diameter | 7.795 |
| Heavy Duty Supplier | Yes |
| Number Of Mounting Bores | 24 |
| Flywheel Cup Depth/Step Height | 0 |
| Number of Teeth | 152 |
| Dowel Hole Pattern | 3 |
| Has Dowel Pins | without Dowel Pins |
| Bolt Hole Pattern | 3 |
| Ring Gear Chamfer Position @ 6:00 O´clock | Left |
| Ring Gear Chamfer Side | Engine |
| Flywheel friction surface outer diameter | 330 |
| Crank Hole Dia. | 14 |
| Number of teeth, starter ring gear | 152 |
| Bolt hole PCD crankshaft | 110 |
| Flywheel Friction Surface Inner diameter | 198 |
| Ring Gear Number | L-01180-0909-00 |
| Ring Gear Major Dia. | 15.349 |
| Flange Thickness | 16.25 |
| I.D. for Pilot | 25.4 |
| Ring Gear Mounting O.D. | 365.836 |
| Crank To Friction Surface | 38.25 |
| Overall Casting O.D. | 379 |
| Ring Gear Thickness | 0.563 |
| Bolt hole PCD clutch pres.plte | 358.8 |
| Flywheel Thickness [mm] | 42.4 |
| Centering diameter / dowel hole | 345 |
| Dowel hole diameter | 7.963 |
| Part Terminology | Clutch Flywheel |
