| Solid Or Vented Type Rotor | Vented |
| Hat Finish | coated |
| Discard Thickness | 16.000 |
| Nominal Thickness | 17.900 |
| Outside Diameter | 289.600 |
| Nominal Drum Diameter | 6.693 |
| Overall Height | 67.500 |
| Disc Finish | Fully Coated |
| ABS Sensor Ring Included | No |
| Surface Type | Smooth |
| California Proposition 65 Text [basic] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 2 |
| Vane Style [cntrc] | Straight |
| Disc Mounting [cntrc] | Floating / DIH |
| Weight [cntrc] kgs | 5.450 |
| Weight [cntrc] lbs | 12.000 |
| Max PB Drum Dia [cntrc] mm | 171.000 |
| Max PB Drum Dia [cntrc] in | 6.732 |
| California Proposition 65 Site [basic] | https://www.p65warnings.ca.gov/ |
| Part Terminology | Disc Brake Rotor |
