| Venturi Quantity | 1 |
| Housing Material | Aluminum |
| Throttle Body Actuation Type | Electric |
| Outlet Quantity | 1 |
| Is Prop Sixty Five Affected | No |
| Inlet Type | Circle |
| Is the item CARB affected | No |
| Throttle Position Sensor Included | Yes |
| FAQs | Will I have to modify anything on the vehicle to install your new throttle body? |
| Is Or Contains A Battery | No |
| Product Condition | New |
| Gasket Or Seal Included | No |
| Outlet Diameter | 2.598 |
| Terminal Type | Blade |
| Throttle Body Outlet Shape | Round |
| FAA_A6 | A relearn calibration procedure is necessary after installation of replacement throttle body. |
| FAA_A7 | Swapping your throttle body for one with a bigger bore is not recommended. The throttle bodies we sell are specific to the application. |
| FAA_A4 | When an electronic throttle body fails, the controlling module will illuminate the MIL/SES/CEL. The module will then activate a fail-safe mode operation and gradually reduce the engine’s speed back to an idle RPM. |
| Contains Electronic Components? | Circuit Board |
| FAA_A5 | The most common failure in an electronic throttle body is the integrated throttle position sensor. The ETB is equipped with high and low voltage reference throttle position sensor for redundancy. Either one of these sensors could fail, or possibly both. |
| FAA_A2 | When installing the new electronic throttle body, there is no need to modify the vehicle for installation. |
| Adjustable | No |
| FAA_A3 | The electronic throttle body is a powertrain component that has a plate, motor, and integrated position sensors which are utilized to regulate the amount of air entering the engine by opening the throttle valve to a desired angle via commands from the vehicle’s powertrain control module or throttle actuator control module. |
| FAA_A1 | The new electronic throttle body is engineered and manufactured to match the O.E. design. |
| Prop 65 | NO |
| FAA_A8 | We do not sell throttle body spacers, nor do we recommend the use of a spacer. |
| Fuel Injectors Included | No |
| FAA_A9 | The purpose of the attached coolant hoses is to keep the throttle body warm by the transfer of heat from the coolant to the housing, preventing moisture from freezing between the throttle body bore and throttle valve during extreme cold temperatures. |
| Outlet Type | Round |
| Idle Air Control Motor Included | No |
| E-Waste | Yes |
| Is Item A Chemical | No |
| FAQ_Q5 | What causes the electronic throttle body to fail? |
| FAQ_Q4 | What happens when an electronic throttle body fails? |
| Features and Benefits | Each unit is guaranteed to fit and function like the original. |
| Is or contains a bulb? | No |
| FAQ_Q7 | Can I purchase a throttle body with a bigger bore to increase horsepower and improve my throttle response? |
| Throttle Body Inlet Shape | Circle |
| FAQ_Q6 | Is there anything that has to be done after installing the replacement throttle body? |
| FAQ_Q1 | Are your new throttle bodies the same design as O.E.? |
| FAQ_Q3 | What’s an electronic throttle body? |
| FAQ_Q2 | Will I have to modify anything on the vehicle to install your new throttle body? |
| Fuel System Type | Gas |
| Bore Diameter | 2.559 |
| Package Contents | Electronic Throttle Body; Instruction Sheet |
| Does it require SDS | No |
| FAA_A12 | The throttle body is also part of the cruise control, traction control, stability control, and pre-crash systems, as well as other systems that require engine torque management. |
| Fuel System Grade | Regular |
| Inlet Diameter | 2.598 |
| FAA_A11 | Not all throttle bodies have this feature, where the throttle valve is reversed from its normal movement by the control module, which breaks up any ice formation between the throttle bore and valve. This feature is based on application. |
| FAA_A10 | No, bypassing the coolant hoses is not recommended. There are cases where we sell units without coolant pipes, because we are following O.E. supersessions where the pipes have been removed. Instructions are provided for rerouting coolant hoses. |
| Outlet Diameter (mm) | 66 |
| Is item a chemical? | No |
| Throttle Body Spacer Included | No |
| FAQ_Q9 | The O.E. throttle body has coolant hoses attached. What’s the purpose? |
| SDS Required | No |
| Alliance Keywords | ETB, ETB Connectors, Electric Throttle Body |
| FAQ_Q8 | Do you sell throttle body spacers? |
| Throttle Body Finish | Natural |
| Bore Diameter (mm) | 65 |
| Housing Color/Finish | Gray |
| Throttle Body Type | Electric |
| Is the item CARB affected? | No |
| FAQ_Q10 | Is it OK to bypass the coolant hoses? |
| FAQ_Q12 | What else does the throttle body control other than idle air bypass and acceleration throughout driving range? |
| Mounting Hardware Included | No |
| FAQ_Q11 | Do all throttle bodies have an ice-breaker mode for extreme cold starts? |
| Throttle Body Type | Electric |
| Is Or Contains A Bulb | No |
| Is or contains a battery? | No |
| Original Equipment Replacement | Yes |
| Contains Electronic Components | Circuit Board |
| Throttle Body Material | Aluminum, Steel, Plastic |
| Inlet Diameter (mm) | 66 |
| Part Terminology | Fuel Injection Throttle Body |
