Product Details
expand_less
| Tooth Quantity |
168 |
| Mounting Hole Diameter |
11.5 |
| Outside Diameter |
14.125 |
| LineCode |
ATP4 |
| Pitch Flywheels |
12 TO 14 |
| Weight Added |
Y |
| Teeth |
168 |
| Contents or Additional Details |
For externally balanced engine |
| SFI Approved |
N |
| Safety Rating |
N/A |
| SFI Certification Sticker Included |
N |
| Diameter (mm) |
358.775 |
| Diameter (in) |
1.177 |
| Heavy Duty Supplier |
No |
| Part Terminology |
Automatic Transmission Flexplate |
Features & Benefits
expand_more
Vehicles with automatic transmissions have a flex plate. Flex plates connect the engine and transmission. Most flex plates are made of a thick piece of sheet metal with bolt holes for the torque converter and teeth for the starter. The job of a flex plate is to allow for expansion of the torque converter as engine RPM increases. The constant expansion and contraction of a flex plate over time can result cracks and/or shearing of the flex plate. A damaged flex plate can create serious (expensive) damage. Broken flex plates can not be repaired, they must be replaced. ATP flex plates are made of high quality steel and contain the correct bolt hole spacing and ring gear teeth just like the original part to ensure long life and durability
Application Summary
expand_more
Buick LeSabre 75, Chevrolet Bel Air 75-70, Chevrolet Biscayne 72-70, Chevrolet Brookwood 72-70, Chevrolet C10 80-76, Chevrolet C20 80-76, Chevrolet C20 Suburban 80-76, Chevrolet C30 78-76, Chevrolet Camaro 71-70, Chevrolet Caprice 76-70, Chevrolet Chevelle 71-70, Chevrolet El Camino 76-74, 70, Chevrolet Estate 70, Chevrolet G20 80-75, Chevrolet G30 80-75, Chevrolet Impala 76-70, Chevrolet K10 80-75, Chevrolet K10 Suburban 79-75, Chevrolet K20 80-75, Chevrolet K20 Suburban 80-75, Chevrolet K30 80-77, Chevrolet K5 Blazer 79-75, Chevrolet Kingswood 72-70, Chevrolet Laguna 76-74, Chevrolet Malibu 76-74, Chevrolet Monte Carlo 76-70, Chevrolet Townsman 72-70, GMC C15 78, 76, GMC C1500 80-79, GMC C25 78-76, GMC C25 Suburban 78, GMC C2500 79, GMC C2500 Suburban 80, GMC C35 78-76, GMC C3500 79, GMC G15 76, GMC G25 78-75, GMC G2500 80-79, GMC G35 78-75, GMC G3500 80-79, GMC Jimmy 79-75, GMC K15 78-75, GMC K15 Suburban 78-75, GMC K1500 80-79, GMC K1500 Suburban 80-79, GMC K25 78-75, GMC K25 Suburban 78-75, GMC K2500 80-79, GMC K2500 Suburban 80-79, GMC K35 78-77, GMC K3500 80-79, GMC Sprint 76-74
